型號
Model
|
SM-25-25 |
操作電壓
Connection voltage
|
380V |
電機總功率
Total motor power
|
19KW |
送料速度
Feed speed
|
0.1-1.5M/MIN |
鋸框行程
Stoke of frame
|
210MM |
鋸框運動次數
Number of strokes
|
450Number/min |
最大鋸切直徑
Maximun cutting diameter
|
φ250mm |
最小鋸切直徑
The minimum cutting diameter
|
φ60mm |
木條長度
Length of wood
|
≥500mm |
鋸條數量
Number of saw blades
|
22 |
吸塵口
Suction inlet
|
3×100mm |
每個接口的吸塵數據
Vacuum data perinterface
|
1300立方/小時 |
壓縮空氣
Compressed air
|
≥6ba |
規格(長×寬×高)
Dimensions(Leng×width×heigh)
|
3600×1500×2500mm |
凈重
Net Weight
|
3200kg |
