型號
Model
|
SM-20-20/25 |
SM-30-20/25 |
|
操作電壓
Connection voltage
|
380V |
380V |
|
電機總功率
Total motor power
|
19KW |
22KW |
|
送料速度
Feed speed
|
0.1-1.5M/MIN |
0.1-1.5M/MIN |
|
鋸框行程
Stoke of frame
|
210MM |
210MM |
|
鋸框運動次數
Number of strokes
|
480Number/min |
480Number/min |
|
鋸切高度（無極調節）
Cutting height(flexble adjustalk)
|
60-200mm/250mm |
60-200mm/250mm |
|
鋸切寬度（用側靠檔）
Cutting width side guide
|
60-200mm |
160-300mm |
|
鋸切寬度（用中靠檔）
Cutting width center guide
|
2×30-90mm |
2×30-150mm |
|
多排進料通道數量，帶7.5mm軌道（木方寬度可變）
Number of channels with 7.5mm guidance
|
2個通道最寬95mm
4個通道最寬24mm
|
2個通道最寬150mm |
|
木方長度
Block length
|
≥300mm | ≥300mm |
|
木方高度公差（用中靠檔）
Block height difference/center guide
|
0-2mm |
0-2nm |
|
最小成品厚度
Min.product thickness
|
2mm |
2mm |
|
鋸切高度在200mm一下的鋸切精度
Cutting precision upto 120mm cutting height
|
±0.1mm |
±0.1mm |
|
鋸條數量
Number of saw blades
|
24 |
24 |
|
吸塵口
Suction tubes
|
3×100mm |
3×100mm |
|
每個接口的吸塵數據
Sution performance per comection
|
1300立方/小時 |
1300立方/小時 |
|
壓縮空氣
Compressed air
|
≥6ba |
≥6ba |
|
規格（長×寬×高）
Dimensions(Leng×width×heigh)
|
3600×930×2500mm | 3600×1030×2500mm |
|
重量
Weight
|
2700kg |
3200kg |
